LINLAI 300B 2.5V tube, Directly heated cathode medium-power triode (1 Pair)

Directly heated cathode medium-power triode, designed for Class A1 amplification
Suitable for applications requiring an output power of 10W
2.5V filament voltage, effectively reduces AC filament noise during DIY amplifier construction
Features black rubber tube base, mildew-shaped screen plate and gold-plated grid wire technology

Filament Specifications
Filament Voltage (Uf): 2.5V
Filament Current (If): 2.4A

Static Electrical Parameters
Anode Voltage (Ua): 300V
Grid Bias Voltage (-Ug): 60V
Anode Current (Ia): 60mA
Transconductance (Gm): 5.5mA/V
Internal Plate Resistance (ri): 0.7kΩ
Amplification Factor (μ): 3.85
Output Power (pout): 6.6W

Absolute Maximum Ratings
Maximum Anode Voltage: 480V
Maximum Anode Power Dissipation: 40W

Cathode Current
Self-bias operation: 100mA
Fixed-bias operation: 70mA

Interelectrode Capacitances
Input Capacitance: 9pF
Output Capacitance: 4.3pF
Grid-Plate Capacitance: 15pF
